Rotating Paddle level Switch ; ABS Housing ; Standard 80 degree; G 1 1/2 inch, 220/240 VAC; 50mm length , SS304 [SRP10CC00504]
Rotating Paddle level Switch ; ABS Housing ; Standard 80 degree; G 1 1/2 inch, 220/240 VAC; 50mm length , SS304 [SRP10CC00504]

Rotating Paddle level Switch

Switch

SRP10CC00504
Rotating Paddle level Switch ; ABS Housing ; Standard 80 degree; G 1 1/2 inch, 220/240 VAC; 50mm length , SS304
2,261.76 ZAR
inc
for 1 Each
0 in Stock
Add
Specifications, Prices & Availability may change without notice. Images are for illustration purposes only. E&OE

Specifications

  • Enclosure Material: NEMA 4X (IP65) rated glass-filled nylon / polycarbonate housing
  • Enclosure Color: Industrial Yellow housing
  • Process Connection: 3/4" NPT (Male) threaded fitting
  • Wetted Parts Material: 316 Stainless Steel probe tip
  • Probe Length: Standard insertion probe with threaded tip connection
  • Power Supply: 12–24 VDC
  • Output Signal: SPDT relay or solid-state switch (N.O. / N.C. selectable)
  • Cable Gland / Conduit Port: Integrated cable gland fitting for field wiring
  • Operating Temperature: -40°C to 80°C (-40°F to 176°F)
  • Max Operating Pressure: Up to 150 psi (10 bar)

Key Applications

  • High/Low level alarm detection in industrial tanks
  • Leak detection and pump protection
  • Non-contact/corrosion-resistant liquid detection in water treatment, chemical processing, and OEM machinery
